How to open Acer Extensa 15 (EX215-33) – disassembly and upgrade options

Undo the 11 Phillips-head screws securing the bottom panel to the base.
Insert a thin plastic tool into one of the top two edges to create a gap.
Carefully pry along the sides, the front, and the other side, leaving the back for last.
If the rear clips feel stiff, use a lever tool to pry the zones around the hinges for easier removal.

More info: The inside of the bottom panel reveals the device’s cooling and upgrade options.

Battery Removal

Caution: Handle the battery with care to avoid damage or electrical hazards.

Detach the battery connector from the mainboard by pulling it gently toward the unit.
Undo the two Phillips-head screws securing the battery to the chassis.
Carefully lift and remove the battery from the laptop.

More info: The device can be configured with an optional 50Wh battery, providing up to 8 hours of video playback. The base model includes a 40Wh battery.

You can find compatible batteries here: Buy from Amazon.com (#CommissionsEarned)

Memory Upgrade

Note: The memory is soldered and not user-upgradeable.

More info: The laptop supports up to 16GB of LPDDR5-4800MHz RAM in single-channel mode, sufficient for general use. Choose a configuration that matches your needs when purchasing.

Storage Upgrade

Hint: Handle SSD components carefully to avoid damage or data loss.

Locate the single M.2 slot, which is compatible with 2280 Gen 3 SSDs.
Install the new SSD into the slot at a slight angle, ensuring it is securely seated.

You can find compatible SSDs here: Buy from Amazon.com (#CommissionsEarned)

Connectivity Options

More info: The Wi-Fi 6 card is upgradable and located to the left of the soldered memory chips. This allows for potential upgrades or replacements if needed.

Cooling System Overview

More info: The Acer Extensa 15 features a basic cooling system suitable for general workloads.

The system includes one fan for airflow management.
A single heat pipe directs heat away from critical components.
A decently long heat sink and a heat spreader aid in heat dissipation.

Tip: Regularly clean the fan and heat sink to maintain optimal cooling performance.

Acer Extensa 15 (EX215-33) in-depth review

Acer claims that the Acer Extensa 15 (EX215-33) is meant for small businesses and everyday users. This is valid only if you pick a machine with the optional 1080p IPS panel. We bought a gadget with a TN panel and yes, this one is awful. Since the memory is soldered, choosing a notebook with 16GB LPDDR5 seems like the way to go. Our device has just 8GB RAM. While it's still okay for basic work, you'll be in trouble if you want to open more than ten Chrome tabs at once.Three Alder Lake-based processors are available. Our recommendation is to get the 15W 8-core Intel Core i3-N305 unless your [...]
