The Intel Atom Z3735F is power-efficient quad-core SoC by Intel and it’s aimed to be used for budget tablets or 2-in-1 devices. The SoC supports both Android and Windows operating systems and it’s part of the Bay Trail-T platform. It is produced on a 22nm manufacturing process. The CPU is clocked at 1.33GHz and can go up to 1.83GHz due to the Burst frequency technology, but it also lacks the so-called HyperThreading feature we saw in the previous generation Atom processors, so users can rely only on the 4 physical cores instead of the additional 4 virtual.
The SoC also comes with Intel HD Graphics (Bay Trail) GPU based on Gen 7 architecture from Intel. It’s important to note that the graphics processor supports DirectX 11 and has 4 EUs (Execution Units). The clock speed is set to a maximum of 646MHz. The entire SoC is rated ar little less than 4W and the SDP is 2.2W and this makes it perfect for tablets or other devices that use passive cooling system.
Check the prices of all notebooks equipped with Atom Z3735F:
Intel Atom Z3735F - Specs Sheet
|Base CPU frequency||1.33 GHz|
|Number of cores||4|
|Instructions type||32 bits|
|Integrated GPU||Intel HD Graphics (Bay Trail)|
|Base GPU frequency||311 MHz|
|Max. operating temperature||-|
|Release date||05 September 2014|
|Core / Architecture||Bay Trail|
|Max. CPU frequency||1.83 GHz|
|Logical Cores (Threads)||4|
|LL cache||2048 KB|
|Max. GPU frequency||646 MHz|
|Memory Type||DDR3L-RS 1333|
|Max Memory||2 GB|
|Supported technologies||Intel® Virtualization Technology (VT-x) Intel® 64|
Intel Atom Z3735F - benchmark tests
We haven’t benchmarked this CPU yet. We’ll try to test it soon.
