The RX 560X is an upgraded version of the already known Radeon RX 560M. It is based on the Polaris 11/21 CPU (built on 14nm FinFET manufacturing process) with 1024 shader units, but here the clock speed is boosted to 1275 MHz – 73 MHz higher than the older model.
As its older counterpart the RX 560X is equipped with 4 GB of GDDR5 memory @6000MHz effectively. GPU-Z reads a Pixel and Texture Fillrate of 20.4 GPixel/s and 81.6 GTexel/s, which is exactly how the desktop version of the RX 560 performs.
As like the rest of the Polaris-based chips from AMD, the Radeon RX 560 supports the same features like DisplayPort 1.3 and 1.4, HDMI 2.0, AMD FreeSync and DirectX 12 renderer, although the latter is only supported on Windows 10.
AMD Radeon RX 560X (4GB GDDR5) - specs
|Manufacturing Process||14 nm|
|Base frequency||1175 MHz|
|Memory Frequency||1500 MHz|
|Memory bandwith||96.0 GB/sec|
|Power consumption||65 W|
|Maximum frequency||1275 MHz|
|Memory Capacity||4 GB|
|Supported technologies||DisplayPort 1.3/1.4 Ready, HDMI 2.0, AMD FreeSync, DirectX 12|
